Mocom millennium B - SEQUENCE OF THE PROCESS; 3 rd pressure pulse - PP3

Rev. 1
Page 2-
17
3
rd
pressure pulse – PP3
After the last vacuum phase, the pressure in the sterilization chamber must rise to the value set for the sterilization process (3rd PRESSURE
PULSE), always through the injection of steam.
1 134°C POROUS
3. PRESSURE PULSE
128.6 °C
1.70 bar 12:33
CHAMBER
Water
tank
DESCRIPTION
STATUSES
(P, t)
VP WP
EV1
(no)
EV2
(nc)
EV3
(nc)
EV4 EV5
(no)
EV6
(nc)
Fan
from –0,80 to 0,00 bar
(water entry5” at –0,80
bar)
from +0,00 to +0,90 bar
3
rd
pressure pulse
from +0,90 to +1,00 bar
OFF ON ON OFF OFF OFF ON ON ON
