P/N Description Ref. Exploded view
A#5BP5410000 Board assembly (GAM version) 61 3
C#5BP1410000 CPU board (GAM version) 61a 3
C#5BP1400000 Power board (GAM version) 61b 3
C#5BP1420000 Filter board (GAM version) 61c 3
C#5BP1430000 Printer power supply board (GAM version) 61d 3
A#5BM4760000 Board assembly (TROLL version) 61 3
C#5BM1400000 Basic board (TROLL version) 61ab 3
C#5BM1420000 Filter board (TROLL version) 61c 3
C#5BM1430000 Printer power supply board (TROLL version) 61d 3
C#1BP145000M Board assembly bracket 62 3
286#00290000 LP1 filter holder 63 2
472#00030000 LP1 filter 65 2
111#000009W0 Rubber protection 67 4
260#000006V0 Charge/discharge fast coupling connector 68 4
A#2BP2380000 Flat cable 9 poles 69 4
C#1BP195000M Closing door access window cover 70 4
256#00000400 PVC foot 71 4
256#00001000 Rubber foot 72 4
55V702016000 Ground bar 73 4
C#1BP147000M Board assembly fixing plate 74 4
C#1BP269000M Top angle bar 75 4
C#1BP270000M Side angle bar 76 4
