Mocom millennium B - Page 282

Rev. 1
Page 4-
16
P/N Description Ref. Exploded view
C#1BP150000M Chassis 77 4
A#0BP2860000 Water pump assembly 78 4
400#00220000 Water pump 78a 4
401#00030000 Electrovalve 2-way (EV6) 78b 4
261#000009MN Angle pipe fitting 79 4
472#00020000 Filter “Saeco” 80 4
111#000006W0 Adhesive mousse 81 4
256#00000800 Shock absorber 82 4
400#00050000 Water pump wire bracket 83 4
A#0BP2810000 Steam generator assembly 84 4
C#1BP136000M Steam generator bracket 84a 4
C#0BP1310000 Thermal insulating spacer 84b 4
C#4BP2360000 Lower thermal insulating panel 84c 4
C#4BP2390000 Thermal insulating sheet 84d 4
C#0XP007000P Steam generator bottom section 84e 4
481#00080000 Steam generator O-Ring 84f 4
C#0BP137000P Steam generator top section 84g 4
410#00130000 Cartridge resistor 85 4
430#00180000 Thermal probe PT1000 86 4
286#0014000N Thermal probe fixing nut 87 4
286#00160000 Thermal probe bush 88 4
430#00150000 Thermostat 89 4
A#0BM3100000 Vacuum pump assembly 90 4
