Rev. 1
Page 4-
17
P/N Description Ref. Exploded view
400#00150000 Vacuum pump head central gasket 90b 4
400#00170000 Vacuum pump hole membrane 90c 4
400#00240000 Vacuum pump recessed-screw membrane 90d 4
400#00180000 Vacuum pump head shutters 90e 4
400#00120000 Vacuum pump head 90f 4
C#1BP151000M Rear chassis 91 5
A#0BS0520000 Safety valve assembly (TUV) 92 5
C#1BS020000P Safety valve bracket 92a 5
470#00020000 Safety valve 92b 5
A#1BP1640000 Heat exchanger assembly 93 5
404#00040000 Heat exchanger protection grid 93a 5
C#1BP160000 Heat exchanger 93b 5
C#1BP159000M Heat exchanger holder 93c 5
404#00030000 Electric fan 93d 5
A#0BP2850000 EV5 assembly 94 5 / 6
401#00240000 EV5 3-way electrovalve 94a 6
55V432011000 EV5 bracket 95 5 / 6
A#0BP2820000 EV1 assembly 96 5 / 6
401#00240000 EV1 3-way electrovalve 96a 6
C#1BP241000M EV1 bracket 97 5 / 6
A#0BP2830000 EV2/EV3 assembly 98 5 / 6
401#00030000 EV2 2-way electrovalve 98a 6
401#00230000 EV3 2-way electrovalve 98b 6
A#0BP2840000 EV4 assembly 99 5 / 6
