Rev. 1
Page 4-
18
P/N Description Ref. Exploded view
401#00260000 EV4 3-way electrovalve 99a 6
C#1BP173000M EV2/EV3/EV4 bracket 100 5 / 6
A#0BP2870000 Automatic water filling pump assembly 101 5
400#00220000 Automatic water filling pump 101 5
472#00020000 Filter “Saeco” 102 5
417#00060000 Fuse holder 103 5
417#00040000 Fuse F16A 6,3x32 104 5
261#000014V0 Plastic T-type fitting 105 5
A#2BP2630000 External tank level probe cable 106 5
277#00001400 Cable tight 107 5
A#2XP0160000 Mains cable 108 5
261#000009MN Angle pipe fitting 109 6
263#000002MN T-type fitting - FFF 110 6
261#000001MN Straight pipe fitting 111 6
266#000003MN Fitting plug 1/8 112 6
263#000003MN T-type fitting - FMF 113 6
265#000009MN Coupling 114 6
262#000003MN Angle fitting FM 115 6
261#000010MN Angle pipe fitting 116 6
261#000004MN Straight pipe fitting 117 6
470#00010000 One-way valve 118 6
A#2BP2220000 Door microswitch cable A1 7
A#2BP2230000 Thermostat cable A2 7
A#2BP2240000 Mains switch cable A3 7
