Rev. 1
Card Gr5-
4
ELECTROVALVES
A#2BP2280000
Before servicing, switch off the equipment and unplug the power
supply cable from the mains socket
1. Remove the covers (see card Gr7-1 );
2. Disconnect the wiring from the electro-valves and power board;
3. Replace the wiring, restore connections and assembly all items proceeding in
reverse order as above;
4. Run a sterilization cycle.
