where:
Rd is the destination register. If Rd is omitted, it is assumed to take the same value as
Rm.
Rm is the register holding the value to be shifted.
Rs is the register holding the shift length to apply to the value in Rm.
imm is the shift length.
The range of shift length depends on the instruction:
ASR — shift length from 1 to 32
LSL — shift length from 0 to 31
LSR — shift length from 1 to 32.
Remark: MOVS Rd, Rm is a pseudonym for LSLS Rd, Rm, #0.
24.4.5.3.2 Operation
ASR, LSL, LSR, and ROR perform an arithmetic-shift-left, logical-shift-left,
logical-shift-right or a right-rotation of the bits in the register Rm by the number of places
specified by the immediate imm or the value in the least-significant byte of the register
specified by Rs.
For details on what result is generated by the different instructions, see
Section 24–24.4.3.3
.
24.4.5.3.3 Restrictions
In these instructions, Rd, Rm, and Rs must only specify R0-R7. For non-immediate
instructions, Rd and Rm must specify the same register.
24.4.5.3.4 Condition flags
These instructions update the N and Z flags according to the result.
The C flag is updated to the last bit shifted out, except when the shift length is 0, see
Section 24–24.4.3.3
. The V flag is left unmodified.
24.4.5.3.5 Examples
ASRS R7, R5, #9 ; Arithmetic shift right by 9 bits
LSLS R1, R2, #3 ; Logical shift left by 3 bits with flag update
LSRS R4, R5, #6 ; Logical shift right by 6 bits
RORS R4, R4, R6 ; Rotate right by the value in the bottom byte of R6.
24.4.5.4 CMP and CMN
Compare and Compare Negative.
24.4.5.4.1 Syntax
CMN Rn, Rm
CMP Rn, #imm
CMP Rn, Rm
