Ricoh Aficio SP C232SF - Page 336

Maintenance
326
10
D Using a coin, turn both gray knobs on the fusing unit 90 degrees clockwise
(until the slots are vertically aligned with the marking shown in the illus-
tration below).
E Close the front cover with both hands carefully.
F Turn the power switch to ”aOn”.
BPC065S
BPC046S
