Caster Table Type M41 (D3GW03)
D0CA/D0C9/D0C8/D0CB 2-66 SM
2. Fit the caps [A] in the screw hole of the handle.
3. Attach two pins to the caster table.
Attach the long pin [A] to the right hole and the short pin [B] to the left hole.
4. Attach the bracket [A] to the caster table.
5. Place the optional paper feed unit [B] on the caster table [A].
6. Place the main machine [C] on the optional paper feed unit [B].
7. Pull out the paper feed tray.
