SP3-XXX (Process)
SM Appendices
3-143 D0CA/D0C9/D0C8/D0CB
Appendices
SP Mode Tables
SP No. Large Category Small Category ENG
or
CTL
[Min to
Max/Init./Step]
3 Display / 0.01g/m3/step]
3-310-00
1
ID.Sen. Detection:
Voffset
Voffset reg ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-310-01
1
ID.Sen. Detection:
Voffset
Voffset dif ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-310-02
1
ID.Sen. Detection:
Voffset
Voffset TM (Front) ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-310-02
2
ID.Sen. Detection:
Voffset
Voffset TM (Center) ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-310-02
3
ID.Sen. Detection:
Voffset
Voffset TM (Rear) ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-311-00
1
ID.Sen.
Detection :Vmin
Vmin_K ENG
*
[0.000 to 5.000 /
0.000 / 0.001V/step]
3-312-00
1
ID.Sen. Detection: Vct Vct_reg ENG
*
[0.000 to 5.000 /
0.000 / 0.001V/step]
3-312-01
1
ID.Sen. Detection: Vct Vct_dif ENG
*
[0.000 to 5.000 /
0.000 / 0.001V/step]
3-320-00
1
Vsg Adj.: Execute ID/TM Sensor ENG [0 to 1 / 0 / 1/step]
3-321-00
1
Vsg Adj. Result: Vsg Vsg reg ENG
*
[0.00 to 5.50 / 4.00 /
0.01V/step]
3-321-01
1
Vsg Adj. Result: Vsg Vsg dif ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-321-02
1
Vsg Adj. Result: Vsg Vsg reg (BW) ENG
*
[0.00 to 5.50 / 4.00 /
0.01V/step]
3-321-03
1
Vsg Adj. Result: Vsg Vsg dif (BW) ENG
*
[0.00 to 5.50 / 0.00 /
0.01V/step]
3-321-04
1
Vsg Adj. Result: Vsg Vsg TM (Front) ENG
*
[0.00 to 5.50 / 4.00 /
0.01V/step]
3-321-04
2
Vsg Adj. Result: Vsg Vsg TM (Center) ENG
*
[0.00 to 5.50 / 4.00 /
0.01V/step]
3-321-04
3
Vsg Adj. Result: Vsg Vsg TM (Rear) ENG
*
[0.00 to 5.50 / 4.00 /
0.01V/step]
3-322-00
1
Vsg Adj. Result: Ifsg Ifsg ENG
*
[0.000 to 50.000 /
27.000 /
0.001mA/step]
