Printer Service Mode
D0CA/D0C9/D0C8/D0CB 3-422 SM Appendices
1001 Bit Switch
3 to
7
1001 Bit Switch
004 Bit Switch 4 0 1
bit 0
to5
DFU - -
bit 6 Bypass Tray Paper Direction LEF SEF
Changes the paper direction used with "Machine Setting(s): Any Type" in the
bypass tray. This setting enables the direction of the paper in the bypass tray to
specified
bit 7 DFU - -
1001 Bit Switch
005
Bit Switch 5 0 1
bit
0
Display Finishing Settings Hide settings Display settings
If enabled, users will be able to configure the Collate Settings, Staple Settings, and
Punch Settings from the operation panel. The available Settings will depend on the
device and configured options.
After enabling this BitSw, the settings will appear under:
"User Tools > Machine Features >Printer Features > System"
bit
1
Number of Copies with Paper
Mismatch
Print Single Copy Print All Copies
If a paper size or type mismatch occurs during the printing of multiple copies, only a
single copy is output by default. Using this bit switch, the device can be configured to
print all copies even if a paper mismatch occurs.
bit
2
GPS Filter Enabled Disabled
If the GPS Filter is disabled, SDK applications will not be able to alter the print data
standard printer applications receive. Note: The main purpose of this BitSw is for
troubleshooting the effects of SDK applications on data.
bit
3
PS Trigger for PDL Switching Standard pattern Pattern1
Specifying the auto detection algorithm for PS while switching the print language.
If the Pattern1 is selected, "%%" is used as a printer system PS trigger.
bit
4
Increase max. number of stored
jobs.
Disabled (100) Enabled (750)
Changes the maximum number of jobs that can be stored on the HDD. The default
(disabled) is 100. If this is enabled, the max. will be raised to 750 or 1000 depending
To Next Page
