ID 442426.04 153WE KEEP THINGS MOVING
Basic properties
8
Manual SD6
8.2.2 DriveControlSuite
You can place the drive in operation with the DriveControlSuite software. Select
an application in the software and parameterize it for your purposes.
DriveControlSuite also provides extensive options for diagnostics, for example
scope functionality.
8.3 Access level
There are separate access levels for configuration and parameters. This
causes parameters to be hidden and the configuration view is locked after a
certain level. You can select between levels 0, 1, 2 and 3.
8.3.1 Parameter level
You can select between the following parameter levels:
• 0: Observer; the elementary displays can be seen. General parameters
can be changed.
• 1: Normal; the essential parameters of the selected application can be
observed and changed.
• 2: Extended; all parameters for startup and optimization of the selected
application can be observed and modified.
• 3: Service; Service parameters. They are used to provide comprehensive
diagnostics.
You can set different levels for different interfaces in parameter A10[x]:
• A10[0]: Access via the operator panel on the drive controller
• A10[2]: Access via fieldbus systems CANopen or EtherCAT
• A10[3]: Access via fieldbus systems PROFIBUS or PROFINET
Elements A10[1] and A10[4] have no function.
8.3.2 Configuration level
The configuration level determines the programming options.
• Level 0: No view of the configuration window is available on this level.
You can load and parameterize applications, but not program them.
• Level 1: You can load and parameterize applications on this level. The
application can be opened up to the first program level. You cannot
program.
• Level 2: You can load and parameterize applications. The application can
be opened up to the second program level. You cannot program.
• Level 3: You can program (currently not supported).
Information
On the configuration level only levels 0 to 2 are freely adjustable.
Level 3 enable is currently not supported.
