Number of times IGB has been booted up since the last time the power supply
voltage was turned on.
14.3 Direct connection
A direct connection means the direct connection of a computer with
DriveControlSuite to an SD6 or an IGB network in the same subnet for the
purpose of commissioning, diagnostics or maintenance.
There are two ways to set up a direct connection:
• You can use the automatic connection setup, see section 14.3.2 Setting up
a connection automatically.
• You can make the connection manually, see section 14.3.3 Setting up a
connection manually.
14.3.1 Prerequisites
Note the following rule for the direct connection:
• The socket of the gateway device and the computer's network connection
must have IP addresses on the same subnet.
14.3.2 Setting up a connection automatically
14.3.2.1 Prerequisites
The following rule applies when setting up a direct connection automatically:
• Parameter A166[x] = 1:standard must be set in the drive controller or .
Address reference of the IP addresses and subnetwork masks of the Ethernet
ports.
• Element 0: Interface X3A
• Element 1: Interface X3B
• Element 2: No function
0: error The state of the socket is not known.
1: co connection The socket is not connected with the other
devices.
2: 10 MBit/s There is a connection to a subscriber at a
transmission rate of 10 Mbit/s with full-duplex
capable communication. The subscriber is not
an SD6.
3: 100 MBit/s There is a connection to a subscriber at a
transmission rate of 100 Mbit/s.
Communication with this subscriber is not full-
duplex capable and the subscriber is not an
SD6.
4: link OK There is a connection to a subscriber at a
transmission rate of 100 Mbit/s with full-duplex
capable communication.
A156 IGB number bootups version 0
A166 IP-address-delivery version 1
