ID 442426.04 234WE KEEP THINGS MOVING
Holding brake
11
Manual SD6
CAUTION!
Unexpected machine response!
During external control the brake does not automatically engage after enable
is turned off and when faults occur.
Make certain there is a suitable process in the control unit. Take suitable
measures to ensure safety.
Current setting of the brake control.
11.4 B20 = 64:SSM and 70:LSM - vector control
When calculating t
close
and t
open
note section 11.2 Direct and indirect brake
connection.
Note also the following parameter descriptions for explanations of the function
of the specified parameters.
For control modes with torque specification only. Reference torque or reference
force currently required by the speed controller. The reference value for
consideration on the load side is C09, for consideration on the motor side B18.
F09 brake is open
F08 brake is closed
t
1 sec
Delay due to not
reaching the minimum
release-release time
R
e
le
as
e
b
r
a
k
e
E
n
g
a
ge
b
r
a
k
e
R
e
le
as
e
b
r
a
k
e
F04 t-brake release F05 t-brake set
E170 T-reference version 0
