Manual SD6
14.4.9 Diagnosis
Progress setting up the connection for remote maintenance.
The parameter returns the same information as the blue LED on the front of the
device.
State of the blue LED.
You can use this parameter to represent the state of the blue LED on an
external signal lamp.
The parameter indicates the state of remote maintenance with a hexadecimal
numeric value (length: 32 bits). Each of the four bytes encodes a diagnostic
value.
The Exit Code shows the following causes for terminating remote
maintenance:
A169 remote service advance version 0
0: no remote service desired Remote maintenance is not desired
Blue LED: Off
1: connecting to teleserver The connection to the teleserver is being
established.
Blue LED: Repeatedly lights up very quickly
2: wait for DriveControlSuite
connection
The device is waiting for the connection to
DriveControlSuite
Blue LED: Steady flashing
3: remote service active The connection is completely set up and
remote maintenance can be performed.
Blue LED: Continuously lit
A170 remote service acknowledge version 0
Bit Description
00: LED on
1: LED off
1-7 No function
A178 error remote service version 0
Exit Code Description
00
hex
No remote maintenance is started. This is the initial value after
the drive controller is turned on.
01
hex
The active gateway was changed.
02
hex
Remote maintenance was terminated properly.
03
hex
A remote maintenance request was not detected in the IGB
network for any drive controller. Remote maintenance was
therefore terminated.
The
specifies why
remote maintenance
was exited.
Exit code
The
indicates the error
within the error
category.
error value
The
specifies the
status of remote
maintenance.
status value
The
stands for a group
of errors.
error category
