Manual SD6
Drive controller – braking resistor assignment
Not possible: —
Recommended: X
Possible: (X)
Note the attachment to the drive controller (section 6.6 Bottom brake resistor)!
Dimensions [mm]
4.12 Chokes
To reduce high-frequency currents on electrical cables and thus increase the
interference immunity and availability of drive systems, coils such as network
or output deraters are used – corresponding to your application.
Power chokes involve inductive metal wire coils that reduce undesired
harmonics or distortion in the network (e.g. for commutation of the current
flow). In addition, they relieve the DC-Link circuit capacity of the drive
controller.
Output deraters reduce charge current peaks due to the cycle signal and line
capacity. They make long motor cables possible, increase the motor service life
and reduce harmonic currents.
Type RB 5022 RB 5047 RB 5100
ID no. 45618 ID no. 44966 ID no. 44965
SD6A04 — — X
SD6A06 — — X
SD6A14 — X (X)
SD6A16 — X (X)
SD6A24 X — —
SD6A26 X — —
SD6A34———
SD6A36———
SD6A38———
Type RB 5022 RB 5047 RB 5100
ID no. 45618 44966 44965
Height 300 300
Width 94 62
Depth 18 18
Drilling pattern corresponds to
size
2 1 0 and 1
