Holding brake
11
Manual SD6
If the holding brake is indirectly connected via a contactor (F93), the total
release time t
rel
=F04 + 1.2*F94.
In control modes ASM - V/f control, ASM - slip compensated and ASM -
sensorless vector control (B20), the brake is already set if the speed falls below
the motor-related velocity set in F03 during stopping.
While the brake is set, a braking ramp is used which is calculated from the total
set time t
set
and F03.
If the holding brake is indirectly connected via a contactor (F93), the total set
time t
set
=F05 + 1.2*F95.
Display of the Brakes are set state.
The state is calculated from the brake set time F05 and the activation of the
brake.
• Element 0: Both brakes are set.
• Element 1: Brake 1 is set.
• Element 2: Brake 2 is set.
F08[0] shows whether both brakes are set (after brake engaging time and if
applicable feedback through the brake module).
F08[1] shows whether brake 1 is set (after brake engaging time and if
applicable feedback through the brake module).
Display of the Brakes are released state.
The state is calculated from the brake release time F04 and the activation of
the brake.
• Element 0: Both brakes are released.
• Element 1: Brake 1 is released.
• Element 2: Brake 2 is released.
The parameter shows whether both brakes are released (after brake release
time and if applicable feedback through the brake module). The axis is ready
to move.
The parameter shows whether brake 1 is released (after brake release time
and if applicable feedback through the brake module). The axis is ready to
move.
F03 brake set speed version 0
F08 brake is closed version 0
F08[0] brake is closed all utilized brakes version 0
F08[1] brake is closed brake 1 version 0
F09 brake is open version 0
F09[0] brake is open all utilized brakes version 0
F09[1] brake is open brake 1 version 0
