Manual SD6
9.8.3 Analog inputs
9.8.3.1 AE1
Tau for reference value smoothing for analog input 1.
Wire break monitoring for analog input.
Operating mode of the analog input.
Values of the analog input.
• Element 0: Terminal value of the analog input before filtering.
• Element 1: Filtered value of the analog input before calibration.
• Element 2: Calibrated value of the analog input.
Zero value of the analog input.
Maximum positive value of the filtered analog input.
Maximum negative value of the filtered analog input.
Deadband value of the analog input.
Minimum percentage value of the calibrated analog input.
Maximum percentage value of the calibrated analog input.
F13 AE1 ref low pass filter version 0
F15 wire breakage sensing version 0
Information
The wire break monitoring function is only possible in AE1 mode
F116=2: 4 to 20mA.
0: inactive
1: active
F116 AE1-mode selector version 0
0: -10V to 10V
1: 0 to 20mA An internal precision resistor (shunt 500 ohms)
is integrated into X100.2. A bridge must be set
between X100.1 and X100.2.
2: 4 to 20mA An internal precision resistor (shunt 500 ohms)
is integrated into X100.2. A bridge must be set
between X100.1 and X100.2.
E110 AE1 version 0
F110 Analog input 1 zero value version 0
F111 Analog input 1 maximum positive value version 0
F112 Analog input 1 maximum negative value version 0
F113 Analog input 1 deadband value version 0
F114 Analog input 1 minimum % value version 0
F115 Analog input 1 maximum % value version 0
