Components of the drive system
3
Manual SD6
3.1 Drive controller
3.1.1 Nameplate
UL test mark
UL and cUL (CSA-UL) certified drive controllers with corresponding test mark
meet the requirements of standards UL 508C and UL 840.
Designation Value in the
example
Meaning
Type SD6A06TEX Drive controller type
according to the type
designation
Date 1318 Production week in format
YYWW, in the example
shown here year 2013, week
18
S/N 7000204 Serial number
Nominal connection
voltage
3 x 400 V ~ 
50 Hz
UL: 3 x 480 V ~
50–60 Hz
Nominal connection voltage
Nominal connection
power
2.5 kVA Nominal connection power
Input current 4.0 A Input current
Output data 3 x 3.4 A
0...460 V
0...700 Hz
Output data
Protection class IP20 Protection class
