ID 442426.04 210WE KEEP THINGS MOVING
Motor
10
Manual SD6
Note that the settings described here are adequate for initial commissioning
and for operation with most drives. If you would like to optimize your drive, find
a description in section 15 Optimize.
Type of motor control.
The motor encoder is set in B26.
Switching between linear and quadratic characteristic curve.
Operate motor with or without field weakening.
B20 control mode version 1
0: ASM - V/f-control For asynchronous motors without motor
encoder.
There is no current or torque limiting in this
control mode.
It is not possible to turn on a motor that is
turning (seizing) in this control mode.
1: ASM - V/f-slip compensated For asynchronous motors without motor
encoder.
2: ASM - vector control For asynchronous motors with motor encoder.
3: ASM - sensorless vector
control
For asynchronous motors without motor
encoder.
64: SSM - vector control For synchronous servo motors with motor
encoder.
70: SLM - vector control For synchronous linear motors with motor
encoder.
B21 V/f-characteristic version 0
0: linear Characteristic voltage/frequency curve is
linear. Suitable for all applications.
1: square Quadratic characteristic curve for use with
fans and pumps. The characteristic curve is
extended linearly starting at the nominal
frequency (B15).
B91 field weakening version 0
