7.2.2.1 Line fuse
The mains fuse ensures line and power protection in the drive controller.
You can use the following protective devices:
• Full range safety melt fuses for cable and circuit protection to IEC 60269-
2-1/DIN VDE 0636, part 201 NH fuses (operating class gG in accordance
with IEC operating class specification or slow blow in accordance with
VDE)
• Circuit breaker with trigger characteristics C in accordance with EN 60898
• Power circuit breaker
The following applies to size 3 (SD6A34, SD6A36, SD6A38):
Operation only with mains commutation reactors and mains fuse for operating
class gG (see section "Line fuses" > "Full range safety melt fuses").
UL-compliant line fuse
Use the following fuses for UL-compliant operation:
• Fuses of class RK1, for example Bussmann KTS-R-xxA/600 V.
• For drive controllers sizes and 1 you can also use fuses of class CC.
• For drive controllers size 0 to 2 you can also use type E motor starters from
Eaton Industries, consisting of a motor protection switch and supply
terminal.
See the table below for suitable fuses:
Type Input current
I
1N,PU
(8 kHz)
Input current
I
1N,PU
(4 kHz)
Recommended
mains fuse (max.)
SD6A02 5.9 A 8.3 A 10 A
SD6A04 2.2 A 2.8 A 10 A
SD6A06 4 A 5.4 A 10 A
SD6A14 9.3 A 12 A 16 A
SD6A16 15.8 A 19.2 A 20 A
SD6A24 24.5 A 26.4 A 35 A
SD6A26 32.6 A 38.4 A 50 A
SD6A34 37 A 45.3 A 50 A
SD6A36 62 A 76 A 80 A
SD6A38 76 A 76 A 80 A
Information
Note that these values apply only to the drive controllers that are
connected to the mains individually. Different parameters apply to
drive controllers in a Quick DC-Link system.
Type Class CC Class RK1 Type E motor starters
(Eaton Industries)
SD6A02 10 A 10 A PKZM0-10/SP + BK25/3-PKZ0-E
SD6A04 10 A 10 A PKZM0-10/SP + BK25/3-PKZ0-E
SD6A06 10 A 10 A PKZM0-10/SP + BK25/3-PKZ0-E
SD6A14 15 A 15 A PKZM0-16/SP + BK25/3-PKZ0-E
SD6A16 20 A 20 A PKZM0-25/SP + BK25/3-PKZ0-E
SD6A24 – 35 A PKZM0-32/SP + BK25/3-PKZ0-E
SD6A26 – 50 A PKZM4-50 + BK50/3-PKZ4-E
SD6A34 – 50 A –
SD6A36 – 80 A –
SD6A38 – 80 A –
