Stober SD6 - Power Board; Size 0: Sd6 A0 X

ID 442426.04 30WE KEEP THINGS MOVING
Technical data
4
Manual SD6
4.2.2 Power board
4.2.2.1 Size 0: SD6A0x
Properties of the brake chopper
Type SD6A02 SD6A04 SD6A06
U
1PU
1 x 230 V,
+20 % / -40 %, 50/60 Hz
3 x 400 V,
+32 % / -50 %, 50/60 Hz;
3 x 480 V,
+10 % / -58 %, 50/60 Hz
f
2PU
0 – 700 Hz
U
2PU
0 – max. U
1
P
V,PU
(I
2
= I
N
) 80 W 65 W 90 W
Type SD6A02 SD6A04 SD6A06
f
PWM,PU
4 kHz
a)
a) Clock frequency adjustable from 4 to 16 kHz, see section 4.2.2.5 Derating.
I
1N,PU
8.3 A 2.8 A 5.4 A
I
2N,PU
4 A 2.3 A 4.5 A
I
2maxPU
180 % for 5 s; 150 % for 30 s
Type SD6A02 SD6A04 SD6A06
f
PWM,PU
8 kHz
a)
a) Clock frequency adjustable from 4 to 16 kHz, see section 4.2.2.5 Derating.
I
1N,PU
6 A 2.2 A 4 A
I
2N,PU
3 A 1.7 A 3.4 A
I
2maxPU
250 % for 2 s; 200 % for 5 s
Type SD6A02 SD6A04 SD6A06
U
onCH
400 – 420 V 780 – 800 V
U
offCH
360 – 380 V 740 – 760 V
R
2minRB
100 Ω
P
maxRB
1.8 kW 6.4 kW
