Technical data
4
Manual SD6
Dimensions [mm]
4.11.2 FGFKU
Properties
The internal connections are wired with heat-resistant, silicon-insulated
strands of wire on terminals. Also ensure a heat-resistant and stress-resistance
design for the connection!
Conductor cross-section
Type FZMU 400x65 FZZMU 400x65
ID no. 49010 55445 53895 55447
L x D 400 65 400 65
H 120 120
K6.5 12 6.5 12
M 430 426
O 485 450
R 92 185
R 64 150
X10 10
RR
FZMU FZZM(U)
L
UUO
KK
M
K
U
M
X
H
øD
Drill pattern
Type FGFKU
ID no. 55449 55450 55451 53897
Resistance [Ω]22151515
Power [W] 2500 6000 8000
Therm. time const. τ
th
[s] 30 20 20
Pulse power for < 1 s [kW] 50 120 160
U
max
[V] 848 848 848
Weight [kg] Approx. 7.5 12 18
Test marks
Connection type Conductor cross-section [mm
2
]
Rigid 2.5 – 10
Flexible with cable end sleeve 2.5 – 10
