ID 442426.04 60WE KEEP THINGS MOVING
Technical data
4
Manual SD6
Braking resistor – drive controller assignment
Not possible: —
Recommended: X
Possible: (X)
Dimensions [mm]
Type FGFKU
ID no. 55449 55450 55451 53897
SD6A24 X———
SD6A26 X———
SD6A34(X)XXX
SD6A36(X)XXX
SD6A38(X)XXX
Type FGFKU
ID no. 55449
55450
55451 53897
A 270 370 570
B 295 395 595
C 355 455 655
490 C
A
B
Ø10,5
380
260
A
10,5
380
Drill pattern
