Stober SD6 - Terminal Modules; Specification - XI6

ID 442426.04 45WE KEEP THINGS MOVING
Technical data
4
Manual SD6
4.8 Terminal modules
4.8.1 Specification - XI6
X100 specification
X101 specification
General specification
Maximum cable
length
30 m, shielded
Electrical data
Analog inputs 
AE1 and AE2
Level ±10 V
Resolution 16 bits
Internal resistance > 40 kΩ
Refresh rate Cycle time of the
application
Analog input 
AE1 as current input
(AE1+ and AE1 shunt
bridged)
Level ±20 mA
Resolution IO6: 12 bits
XI6, RI6: 16 bits
Internal resistance 492 Ω
Wire break monitoring Parametrizable in F15
Analog outputs 
AA1 and AA2
Level ±10 V
Maximum output current XI6: 10 mA
IO6, RI6: ± 20 mA
General specification
Maximum cable
length
30 m, shielded
Electrical data
Binary inputs 
BE1 to BE3
Low level 0–8 V
High level 12–30 V
Input voltage Max. 30 V
Input current Max. 16 mA
Input frequency Max. 10 kHz
Binary inputs 
BE4 and BE5
Low level 0–8 V
High level 12–30 V
Input voltage Max. 30 V
Input current Max. 16 mA
Input frequency XI6: max. 100 kHz
IO6, RI6: max. 250 kHz
Binary outputs 
BA1 and BA2
Maximum output current XI6: 50 mA 
IO6, RI6: 100 mA
Typical voltage drop < 2 V
Refresh rate Cycle time of the
application (at least 1
ms)
Output frequency Max. 250 kHz
24 vdc power supply Input voltage 18–28.8 V
