ID 442426.04 46WE KEEP THINGS MOVING
Technical data
4
Manual SD6
X102 specification
X103A specification
General specification
Maximum cable
length
30 m, shielded
Electrical data
Analog input AE3 Level ±10 V
Resolution 16 bits
Internal resistance > 40 kΩ
Refresh rate Cycle time of the
application (at least 1
ms)
General specification
Maximum cable
length
30 m, shielded
Electrical data
Binary outputs 
BA3 and BA4
Maximum output current 50 mA
Typical voltage drop < 2 V
Refresh rate Cycle time of the
application
Inductive load Max. 1.2 VA
Binary outputs 
BA5 and BA6
Maximum output current 50 mA
Typical voltage drop < 2 V
Refresh rate Cycle time of the
application
