Manual SD6
4.8.3 Specification – IO6
X100 specification
X101 specification
Electrical data
Analog inputs
AE1 and AE2
Level ± 10 V
Resolution 12 bits
Internal resistance > 40 kΩ
Refresh rate Cycle time of the
application
Analog input
AE1 as current input
(AE1+ and AE1 shunt
bridged)
Level ± 20 mA
Resolution 12 bits
Internal resistance 492 Ω
Wire break monitoring Parameterizable in F15
Analog outputs
AA1 and AA2
(short-circuit-proof)
Level ± 10 V, ± 20mA
Maximum output current ± 20mA
Electrical data
Binary inputs
BE1 to BE3
Low level 0–8 V
High level 12–30 V
Input voltage Max. 30 V
Input current Max. 16 mA
Input frequency Max. 10 kHz
Binary inputs
BE4 and BE5
Low level 0–8 V
High level 12–30 V
Input voltage Max. 30 V
Input current Max. 16 mA
Input frequency Max. 400 kHz
Binary outputs
BA1 and BA2
Maximum output current 100 mA
Typical voltage drop < 2 V
Refresh rate Cycle time of the
application
Binary outputs
BA1 and BA2 as
encoder output
Maximum output current 50 mA
Typical voltage drop < 2 V
Output frequency Max. 1 MHz
24-V power supply Input voltage 18–28.8 V
