Drive controller
9
Manual SD6
The numerator H85 is divided by the denominator H87. This makes it possible
to calculate mathematically exact gear ratios as fractions (gear drives, toothed
belt drives).
The numerator H85 is divided by the denominator H88. This makes it possible
to calculate mathematically exact gear ratios as fractions (gear drives, toothed
belt drives).
9.8.6 Display
The following display parameter provides you with further information:
Terminal value of the binary inputs and of the enable.
9.9 Saving data with protection against power
failure
If you have transferred data from DriveControlSuite to the drive controller or
changed the parameter settings, the data in the drive controller must be saved.
Until the data has been saved, it is not protected for subsequent use against a
power failure or if the power is turned off and back on.
You can save data in the drive controller with action A00 save values. With the
exception of the display parameters, all parameters and the configuration are
stored in the memory module.
You can reach A00 save values
• with the Save key on the operator panel (an explanation of the keys can be
found in section 8.2.1.1 Setup)
• in the operator panel parameter menu (an explanation of the parameter
menu can be found in section 8.2.1.2 Menu structure and navigation)
• (if there is an active direct connection) in the DriveControlSuite parameter
lists (see also the DriveControlSuite manual. The ID of the manual can be
found in section 1.2 Further documentation)
H87 simulation factor denominator version 0
Information
This parameter is only evaluated if the source parameterized in H80
is a master position (selections 1,2,3).
H88 simulation factor denominator version 0
Information
This parameter is only evaluated if the selection 4:Position encoder
is set in H80.
E19 binary inputs version 0
Bit Description Comment
0 Enable
1 -
13
Binary input 1 to binary input 13
14 -
15
Reserved No function
Information
Do not switch off the power supply of the control board while the
save process is still active. If you do turn of the power supply, the
fault *ConfigStartERROR parameters lost or *Paramodul ERROR -
Read error will appear in the display next time the device is
restarted. A description of faults can be found in sections 16.54
*ConfigStartERROR parameters lostand 16.51 *ParaModul
ERROR: file not found.
In this case the application must be transferred to the drive
controller again.
