Technical data
4
Manual SD6
4.10.3 Line fuse
Fuse protection against overload and short circuit
Every drive controller in the compound DC link system supplied with power must be protected by a fuse at the mains input by both overload and short circuit
protection connected in series. A miniature circuit breaker protects against overload and a safety fuse against short circuit.
Information
To ensure problem-free operation, always comply with the recommended trigger limits and trigger
characteristics of the fuse elements.
Size I
1N,PU
[A] I
1maxPU
[A]
Selecting fuse protection
Circuit Breaker Safety fuse
0
SD6A04 2,8 5,0 Fa. EATON
Type: FAZ-B6/3, Art.No.: 278841
Trigger characteristic: B 6 A
Fa. SIBA
Type: URZ, Art.No. 50 140 06.20
Trigger characteristic: gR 20 A
SD6A06 5,4 9,7
1
SD6A14 12,0 21,6 Fa. EATON
Type: FAZ-Z20/3, Art.No.: 278928
Trigger characteristic: Z 20 A
Fa. SIBA
Type: URZ, Art.No. 50 140 06.32
Trigger characteristic: gR 32 A
SD6A16 19,2 34,6
2
SD6A24 26,4 47,5 Fa. EATON
Type: FAZ-Z40/3, Art.No.: 278931
Trigger characteristic: Z 20 A
Fa. SIBA
Type: URZ, Art.No. 50 140 06:80
Trigger characteristic: gR 80 A
SD6A26 38,4 69,1
3
SD6A34 45,3 81,5 Fa. EATON
Type: FAZ-B63/3, Art.No.: 278853
a)
Trigger characteristic: B 63 A
Fa. Siemens
Type: SIRUS, Art.No.: 3RV 1041-4KA10
Trigger characteristic: 57 A – 75 A
b)
a) Reduces the input current from 73 A to 63 A. This causes the power output to be reduced, however reliable rectifier protection is not guaranteed.
b) Circuit breaker size S3, CLASS 10, adjustable current range: 57 A – 75 A, electromagnetic triggering: 975 A. Rectifier diodes are not protected in the range of 2 times to 13 times the nominal current.
Fa. SIBA
Type: URZ, Art.No. 50 140 06.100
Trigger characteristic: gR 100 A
SD6A36 76 136,8
SD6A38 76 136,8
