4.10.1 Electrical Data
When designing and operating the Quick DC-Link, always observe the electrical data and the individual drive controller sizes and types.
The maximum DC link voltage is 750 V and the maximum permitted current is 200 A.
Size (voltage) Type I
1N,PU
[A]
I
2N,PU
[A] 4 kHz
I
2N,PU
[A] 8 kHz
Own capacity
[µF]
Charging
capacity
[µF]
Remaining
charging
capacity
[µF]
0 (1 x 230 V) SD6A02 8.3 4 3 340 1620 1280
0 (3 x 400 V)
SD6A04 2.8 2.3 1.7 135 540 405
SD6A06 5.4 4.5 3.4 135 540 405
1 (3 x 400 V)
SD6A14 12 10 6 470 1405 935
SD6A16 19.2 16 10 560 1405 845
2 (3 x 400 V)
SD6A24 26.4 22 14 680 1405 725
SD6A26 38.4 32 20 1000 1405 405
3 (3 x 400 V)
SD6A34 45.3 44 30 430 5100 4670
SD6A36 76 70 50 900 5100 4200
SD6A38 76 85 60 900 5100 4200
