Technical data
4
Manual SD6
4.12.1 Power choke
WARNING!
Risk of burns! Fire hazard! Material damage!
Chokes can heat up to over 100 °C under permitted operating conditions.
Take protective measures against accidental and intentional contact with
the choke.
Make sure that no flammable material is in the vicinity of the choke.
Do not install chokes under or near the drive controller.
WARNING!
Fire hazard!
Using chokes outside of the nominal data (cable length, current, frequency,
etc.) can cause the chokes to overheat.
Always comply with the maximum nominal data when operating the
chokes.
Type TEP4010-2US00
ID no. 56528
Phases 3
Permitted thermal continuous current 100 A
Rated current 90 A
Rated inductance 0.1410 mH
Mains voltage 480 V
Voltage drop (Uk) 2 %
Frequency 60 Hz
Protection class IP 00
Max. surrounding temperature ϑ
amb,max
40° C
Insulation class B
Connection Flange connection
Mounting Screws
Specification EN 61558-2-20
UL Recognized Component (CAN; USA) Yes
CE mark Yes
Identification/test mark, symbol , ,
