Technical data
4
Manual SD6
Dimensions TEP4010-2US00
Height [mm] 235
Width [mm] 219
Depth [mm] 118
Vertical distance 1 –
fastening holes [mm]
201
Vertical distance 2 –
fastening holes [mm]
136
Horizontal distance 1 –
fastening holes [mm]
88
Horizontal distance 2 –
fastening holes [mm]
75
Drill holes – depth [mm] 7
Drill holes – width [mm] 12
Screw connection – M M6
Weight [kg] 10
