ID 442426.04 47WE KEEP THINGS MOVING
Technical data
4
Manual SD6
X103B specification X103C specification
General specification
Maximum cable
length
30 m, shielded
Electrical data
Binary outputs
BA7 to BA10
Maximum output current 50 mA
Typical voltage drop < 2 V
Refresh rate Cycle time of the
application
Binary input BE6 Low level 0–8 V
High level 12–30 V
Input voltage Max. 30 V
Input current Max. 16 mA
Input frequency Max. 3 kHz
General specification
Maximum cable
length
30 m, shielded
Electrical data
Binary inputs
BE7 to BE13
Low level 0–8 V
High level 12–30 V
Input voltage Max. 30 V
Input current Max. 16 mA
Input frequency Max. 3 kHz
