Terminal value of analog output 1 on X100.6 - X100.8.
Scaled value of analog output 1 before limiting and conversion from % to V.
Relative value of analog output 1 before filtering and formation of value.
Enter the coordinates of the parameter whose value will be exported to AA1 in
F40. As source you can only enter parameters with data type REAL32.
Reference value for the source set in F40.
Tau actual value of analog output 1.
Factor of analog output 1.
Activation of formation of value for analog output 1.
Offset of analog output 1.
Lower limit value of analog output 1.
Upper limit value of analog output 1.
E13[0] analog output 1 terminal value version 0
E13[1] analog output 1 scaled value version 0
E13[2] analog output 1 relative version 0
F40 analog output 1 source version 0
F41 analog output 1 reference source version 0
F42 analog-output1-act low pass filter version 0
F43 analog output 1 gain version 0
F44 analog output1 absolute version 0
F45 analog output 1 offset version 0
F46 analog output 1 lower limit version 0
F47 analog output 1 upper limit version 0
