Drive controller
9
Manual SD6
Terminal value of analog output 2 on X100.7 - X100.8.
Scaled value of analog output 2 before limiting and conversion from % to V.
Relative value of analog output 2 before filtering and formation of value.
Enter the coordinates of the parameter whose value will be exported to AA2 in
F50. As source you can enter all parameters with data type REAL32.
Reference value for the source set in F50.
Tau actual value of analog input 2.
Factor of analog output 2.
Formation of value for analog output 2.
Offset of analog output 2.
Lower limit value of analog output 2.
Upper limit value of analog output 2.
E14[0] analog output 2 terminal value version 0
E14[1] analog output 2 scaled value version 0
E14[2] analog output 2 relative version 0
F50 analog output 2 source version 0
F51 analog output 2 reference source version 0
F52 analog-output2-act low pass filter version 0
F53 analog output 2 gain version 0
F54 analog output2 absolute version 0
F55 analog output 2 offset version 0
F56 analog output 2 lower limit version 0
F57 analog output 2 upper limit version 0
