ID 442426.04 306WE KEEP THINGS MOVING
Optimize
15
Manual SD6
Number of poles of a synchronous servo motor or asynchronous motor.
If the number of pole pairs is specified for third-party motors, the value must be
multiplied by 2 before it is entered.
Correlation between the number of poles, nominal speed n
N
in rpms and the
nominal frequency f
N
in Hz of the motor: B10 = 2·(f
N
· 60/n
N
).
Entry point into field weakening.
The set value affects the dynamic properties of the drive.
Setting instructions:
• The smaller the value the better the dynamic properties.
• The larger the value the lower the power consumption at a given working
point.
DC link connection (peak value).
Motor voltage (chained RMS value).
Frequency of the voltage applied to the motor.
The speed determined from the motor encoder specified in B26. If the control
mode in B20 does not require an encoder and none is parameterized in B26,
the speed from the motor model will be displayed.
Currently active positive torque/force limit. The reference value for
consideration on the load side is C09, for consideration on the motor side B18.
Currently active negative torque/force limit in reference to B18. The reference
value for consideration on the load side is C09, for consideration on the motor
side B18.
Display of the current torque or force as a percentage. Unsmoothed, in contrast
to E02. The reference value for consideration on the load side is C09, for
consideration on the motor side B18.
Display of the current motor speed. Unsmoothed, in contrast to E08. If the drive
is operated without feedback, this speed is determined by calculations using
the motor model (the actual motor speed may differ in this case from the
calculated speed).
B10 motor-poles version 0
B92 voltage limit field weakening version 0
E03 DC-link-voltage version 0
E04 U-Motor version 0
E05 f1-Motor version 0
E15 v-motor-encoder version 0
E65 actual positive T-max version 0
E66 actual negative T-max version 0
E90 actual torque/ force version 0
E91 v-motor version 0
