ID 442426.04 368WE KEEP THINGS MOVING
Diagnosis
16
Manual SD6
16.3 33:Overcurrent
Triggering Level Response Counter
The total motor current exceeds the permitted
maximum value.
Fault The power board is switched off and the drive becomes
torque-free/force-free unless emergency braking U30
(A29) is parameterized (from firmware V 6.0-F). If the air
override is inactive, a possibly existing brake will be
controlled to close.
Z33
Possible cause Test Measure Confirmable
Acceleration times too short. Extend the ramps. Apply this setting for operation. Yes
Incorrectly set torque limits in the C03
and C05 parameters.
Set smaller values in C03 and C05. Apply this setting for operation.
