Diagnosis
16
Manual SD6
16.7 37:Encoder
Triggering Level Response Counter
Error due to encoder Fault The power board is switched off and the drive becomes
torque-free/force-free unless emergency braking U30
(A29) is parameterized. If the air override is inactive, a
possibly existing brake will be controlled to close.
If the encoder is parameterized as a position encoder,
reference I86 is deleted and the axis must be
rereferenced after the acknowledgement.
If the encoder is not connected when switching on the
control part power supply, the encoder supply is switched
off. Acknowledgement is then only possible by switching
the drive controller off and on.
Z37
Cause Description Measure Confirmable
1:Para<>Encoder Parameterization is not suitable for the
connected encoder.
Check the setting of the H00 parameter. Yes
2:maximum speed B297 exceeded • Check the connection and shielding of
the encoder cable.
• Reduce the electromagnetic
interference.
• Check the parameterization of B297.
• Please contact our Service department.
Yes
6:X4-EnDatfound An EnDat encoder was detected at X4
although a different encoder was
parameterized.
Check the setting of the H00 parameter. Yes
7:AX6/IncEnc A wire break in the A-channel was discover
on X4 with an incremental encoder.
Check the encoder cable of the incremental
encoder.
Yes
