Diagnosis
16
Manual SD6
16.9 39:TempDev i2t
Triggering Level Response Counter
The i2t model for the drive controller is exceeding
the maximum allowable thermal utilization.
From firmware V 6.0-G: A27
To rom firmware V 6.0-F: 100%
Parameterized
level in U02:
•Inactive
• Message
• Warning
•Fault
Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
If the event is triggered at a threshold of 100%, current
limiting is performed in the control modes with vector
control. Reducing the current can cause the fault quick
stop to no longer perform correctly.
Z39
Possible cause Test Measure Confirmable
Drive controller overloaded Check the load situation of your drive. • Correct the design of the drive.
• Check the maintenance condition of the
drive (block, lubrication, etc.)
Yes
Cycle frequency too high (B24) Check the load situation of your drive under
consideration of the derating.
• Reduce B24.
• Use a drive with a suitable power rating.
