Diagnosis
16
Manual SD6
16.17 47:TorqueLimit
Triggering Level Response Counter
The maximum torque permitted for static operation
is exceeded in the control types of servo control,
vector control or sensorless vector control.
Parameterized
level in U20:
•Inactive
• Message
• Warning
•Fault
Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
Z47
Possible cause Test Measure Confirmable
Incorrect parameterization Check whether the torque moments in E62
and E66 correspond with your projection.
Correct the setting of the parameters in C03,
C05, A559 or I435 and I436.
Yes
Drive overloaded Check the load situation of your drive. Rectify any existing blockages.
