Diagnosis
16
Manual SD6
16.28 58:Encoder simulation
Triggering Level Response Counter
An error was discovered in encoder simulation. Fault Parameterized fault response in A29:
• A29 = 0:inactive
The power board is switched off and the drive
becomes torque-free/force-free. If the air override is
inactive, a possibly existing brake will be controlled to
close.
• A29 = 1:active
The drive is stopped with a quick stop. If the air
override is inactive, a possibly existing brake will be
controlled to close at the end of the quick stop.
Z58
Cause Description Measure Confirmable
1:Maximum speed The maximum speed of simulation has been
reached.
Check the parameterization of encoder
simulation.
Yes
3:X120-Wire break channel A/Clock A wire break was detected at interface
X120.
• Check the wiring.
• Check the setting in H120.
4:X120-Wire break chan. B/Data A wire break was detected at interface
X120.
• Check the wiring.
• Check the setting in H120.
5: X120-Wire break chan. 0 A wire break was detected at interface
X120.
• Check the wiring.
• Check the setting in H120.
