ID 442426.04 424WE KEEP THINGS MOVING
Diagnosis
16
Manual SD6
16.45 82:Hall sensor
Triggering Level Response Counter
Error by Hall sensor. Fault The power board is switched off and the drive becomes
torque-free/force-free unless emergency braking U30
(A29) is parameterized. If the air override is inactive, a
possibly existing brake will be controlled to close.
Z82
Cause Description Measure Confirmable
1: invalid sample The current levels of the three Hall sensors
do not match any sector (only 6 of the 8
possible samples can be assigned to a
sector).
• Check the wiring for a wire break.
• Check the setting of parameter B08 for
an incorrectly selected Hall distance.
Yes
2: invalid sequence The evaluation resulted in a direct switch
between two non-adjacent sectors.
3: Signal edge missing The axis has moved more than 1.2 times the
length of a Hall sector without one of the Hall
signals having changed.
• Check the setting of parameter B16 for
an incorrectly selected pole distance.
• Check the encoder settings for an
incorrectly parameterized length setting.
