Installation
6
Manual SD6
DL6 – length of copper rails
Quick DC-Link – installation of DL6 modules
Requirements:
• For reasons related to EMC, use mounting plates with a conductive surface
(unpainted, etc.).
• You have tapped holes for threaded bolts on the mounting plate at the
installation location, taking into consideration the different device
dimensions.
• Avoid installation above or in the immediate vicinity of heat-generating
devices
such as output deraters or braking resistors.
• To ensure there is sufficient air circulation in the control cabinet, observe
the minimum clearances.
• The copper rails must be straight, smooth, free of burrs and cleaned.
You need:
• Copper rails (cross-sectional dimension: 5 x 12 mm).
• The threaded bolts enclosed with the DL6 modules as well as the
corresponding screws and washers.
• The insulation inserts and holding clamps enclosed with the DL6 modules.
• A PH2 Phillips screwdriver.
• An 8 mm hexagonal socket wrench.
Clearance of
fastening holes [mm]
SZ 0/1
–
SZ 0/1
SZ 0/1
–
SZ 2
SZ 2
–
SZ 2
SZ0/1
–
SZ 3
SZ 2
–
SZ 3
SZ 3
–
SZ 3
Size 0/1
Vertical
distance
a 283 283 283 — — —
Size 3 a — — — 380 380 380
Drive
controller
Horizontal
distance
b 75 93 110 56 73 45
Drive
controller
with
bottom
braking
resistor
b75 93 110 — — —
Drive
controller
with DL6
b73 ± 291 ± 2
108 ±
2
62 ± 2 79 ± 2 51 ± 2
d — — — 150 150 150
Length of copper rails (5 x 12) [mm]
Size 0/1 Initial dimension c 57
Distance dimension b 73
Size 2 Initial dimension c 90
Distance dimension b 108
Size 3 Initial dimension c 198
Distance dimension b 201
Total length n x distance dimension
+ 2 x initial dimension
