Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
308 (428) 9836 3123 01
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Angle
status OK
Angle result is
within limits.
1 bit
0 = Not used
1 = OK
Tightening result
/ Start new
tightening or new
Pset selected or
new Job selected
Batch done
Indicate batch
finished. Batch
done OK or NOK.
1 bit
0 = Not
completed
1 = Done
Batch finished /
Reset result
X
X
X
X
X
X
Batch
status
Batch OK (done) or
NOK
1 byte
ASCII
character
O = OK
N = NOK
Tightening result
/ Start new
tightening or new
Pset selected or
new Job selected
2 bits
BF
00 = Not used
01 = OK
10 = NOK
Batch
status NOK
Batch is NOK.
1 bit
0 = Not used
1 = NOK
Tightening result
/ Start new
tightening or new
Pset selected or
new Job selected
Batch
status OK
(nxOK)
Batch is OK
(nxOK).
1 bit
0 = Not used
1 = OK
Tightening result
/ Start new
tightening or new
Pset selected or
new Job selected
Battery
empty
Indicates tool
battery empty
1 bit
0 = Not used
1 = Battery
empty
Tool battery empty
/ no signal
X
X
X
X
Battery low
Indicates tool
battery low
1 bit
0 = Not used
1 = Battery low
Tool battery low /
no signal
X
X
X
X
Calibration
alarm
Calibration date
expired. New date
to be entered.
1 bit
0 = Off
1 = On
Calibration date
expired / Reset or
set a new
calibration date
X
X
X
X
Channel ID
Gives the channel
ID number on the
fieldbus Power
Focus.
2 - 8 bits in
the same
byte
BF
0000 0001=CH
1
0001 0000=CH
16
PF ready and
channel ID
programmed in
config / No signal
