Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
9836 3123 01 309 (428)
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
16 bits in
one word
U16
00….0001=CH
1
00….1000=CH
8
Channel
name
Shows C311
Channel name
16-200 bits
CSC, CSCI
Channel name
stored in controller
set / No signal
Current
Indicates tightening
result final current
in percent (%).
2 – 8 bits
BF
Integer number
Tighten result /
Tighten started or
Pset Selected or
Job selected
16 bits
U16
Integer number
Completed
batch
BF
U16
Batch Counter
Changed / No
signal
Completed
batch bit
(0-6)
Display currently completed batch.
X
Cycle abort
Display cycle
aborted by cycle
abort timer expired
1 bit
0 = Not used
1 = Cycle abort
Cycle Abort / Reset
result
X
X
X
Cycle
complete
Indicates that a
tightening is
finished. Do not
care about the
result.
1 bit
0 = Not used
1 = Cycle
complete
Tightening done /
Start new tightening
or new Pset
selected or new Job
selected
X
X
X
X
X
Cycle start
Indicate cycle
started.
1 bit
0 = Not used
1 = Cycle started
Cycle start / Start
new tightening
X
X
DigIn# # =
1-4
Mimic the status on
a DigIn in Power
Focus or I/O
Expander. The
input must be
configured to
fieldbus DigIn # X.
There are four
different items.
1 bit
0 = Input Off
1 = Input On
DigIn # X On /
DigIn # X Off
DigIn
controlled
# 1-4
Controlled by
DigOut monitored 1
– 4 To PF
1 bit
0 = DigIn bit
reset
1 = DigIn bit set
DigIn control1Set /
Reset
X
X
X
X
