Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
9836 3123 01 311 (428)
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Final angle
Final angle result.
2 byte
U16
Binary
representation
(Decimal 0-65
535)
Tightening done /
Start new tightening
or new Pset
selected or new Job
selected
Final angle
start
Indicate final angle
started.
bit
Final Angle Start /
Cycle Completed
Final
torque
Final torque result.
4 byte
The value is 2
digits if torque
value is less than
100, one digit if
100 <= torque
value < 1000 and
0 if torque value
>= 1000. For
example, if
torque value is
25.64, the two
byte integer part
shows 25 and the
two byte decimal
part shows 64; if
torque value is
345.5, the integer
part shows 345
and decimal part
shows 5; if
torque value is
2431, the integer
part shows 2431
and decimal part
shows 0. The
value is
represented in
the selected
engineering units
in the Power
Focus.
Tightening done /
Start new tightening
or new Pset
selected or new Job
selected
Function
button
Function button pressed.
X
X
X
X
Function
button ack.
Function button pressed acknowledge.
X
X
X
X
X
High
Any result is above any of the programmed max limits.
X
X
X
X
X
