Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
316 (428) 9836 3123 01
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Open
protocol
commands
disable
Set when the Open Protocol Commands DigIn has been activated. In this
case all the commands that the Power Focus can receive via Open
Protocol are disabled.
X
X
X
X
Open
protocol
conn lost
Indicates
connection with
open protocol lost.
1 bit
0=connected
1=disconnected
Open protocol
disconnected /
Open protocol
connected
X
X
X
X
PF ready
No severe errors in
PF.
1 bit
0=Errors in PF
1=No errors in
PF
PF ready (no errors)
/ PF not ready
(errors)
X
X
X
X
PIN code
OK
A PIN code entered on the RFID card reader has been validated by the
Power Focus.
X
Positioning
disabled
Positioning function currently disabled.
X
X
X
X
Power ON
Indicates that PF is power supplied.
X
Pset final
angle min /
Pset final
angle max /
Pset step1
speed / Pset
step2
speed/ Pset
rundown
angle min/
Pset
rundown
angle max.
Shows Pset
parameters from the
running Pset. Pset
step1 speed / Pset
step2 speed shown
in percentage of
max speed or rpm
depending on P139
Speed unit.
2 bytes
U16
Binary
representation
(Decimal 0-
65535)
New Pset selected
or updated / No
signal. On until
new Pset is selected
or current Pset
updated
Pset final
target / Pset
final torque
min / Pset
final torque
max / Pset
start final
angle
Shows Pset
parameters from the
running Pset in
selected
engineering units.
4 bytes
Fixed point
See Item
Final Torque.
New Pset selected
or updated / No
signal. On until
new Pset is selected
or current Pset
updated
