Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
9836 3123 01 323 (428)
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Tightening
time
The tightening time
taken from the most
recent result.
Format HH:MM:SS
64 bit (8
characters)
CSC
I.e. 08:15:08
(8 ASCII
characters) 24
hour
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
64 bits
CSCI
I.e. 80:51:80 (
from right to left)
Tightening
time hour
The tightening time
(hour part only)
taken from the most
recent result.
16 bit (one
word)
U16
0 – 24 hour
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Tightening
time min
The tightening time
(minutes only)
taken from the most
recent result.
16 bit (one
word)
U16
0 - 60 min
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Tightening
time sec
The tightening time
(seconds only)
taken from the most
recent result.
16 bit (one
word)
U16
0 - 60 sec
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Tightening
status NOK
Tightening result
has one or more
Not OK results.
1 bit
0 = Not used
1 = NOK
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Tightening
status OK
All tightening result
is OK.
1 bit
0 = Not used
1 = OK
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Tool
connected
Indicates
connection
established between
tool and controller
1 bit
0 = Not used
1 = Tool
connected
Tool is connected /
no signal
X
X
X
X
Tool
disabled
Indicates if the tool
is disabled or not.
1 bit
0 = Tool enabled
1 = Tool disabled
Tool disable / Tool
enable
Tool
enabled
Indicates if the tool
is enabled or not.
1 bit
0 = Tool disabled
1 = Tool enabled
Tool enable / Tool
disable
