Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
324 (428) 9836 3123 01
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Tool green
light
This item follows
the tool green light.
1 bit
0 = Not used
1 = Green
Tightening result
or flash green light
/ Start new
tightening or
Reset LED
X
Tool in
product
space
Tool is located in product space
X
X
Tool in
work space
Tool is located in work space
X
X
Tool
locked
Tool is locked (tool not ready).
X
X
X
X
Tool
loosening
Indicates that the
tool is loosening.
1 bit
0 = Tool is not
loosening
1 = Tool is
loosening
Tool is loosening /
Tool is stopped
X
Tool ready
Indicates that the
tool is ready for
tightening.
1 bit
0 = Tool is not
ready
1 = Tool is ready
Tool is ready /
Tool is not ready
X
X
X
X
Tool red
light
This item follows
the tool red light.
1 bit
0 = Not used
1 = Red
Tightening result /
Start new
tightening
X
Tool
running
Indicates that the
tool is rotating CW
or CCW.
1 bit
0 = Tool is not
run
1 = Tool is
running
Tool is running /
Tool is stopped
X
Tool serial
no
Show tool serial
number after each
tightening
32 bits
U32
Intel Endian 32
bits integer
Tighten result /
Start new
tightening
32 bits
U32_HN
W
Intel Endian 32
bits integer
Tool start
switch
Indicates tool is
switching.
1 bit
0 = Not used
1 = rotating
Tool is rotating /
Tool stopped
X
Tool
tightening
1 bit
0 = Tool is not
tighten
1 = Tool is
tightening
Tool is Tightening
/ Tool is stopped
X
