Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
9836 3123 01 325 (428)
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Tool
yellow
light
This item follows
the tool yellow
light.
(If ”PF_ control _3”
is selected yellow
LED shows the
fatal error and reset
when error
acknowledged)
1 bit
0 = Not used
1 = Yellow
Tightening result
or fatal error / Start
new tightening or
error Ack
X
Tools Net
conn lost
Indicates
connection with
Tools Net lost.
1 bit
0 = connected
1 = disconnected
Tools Net
connection lost /
Connected
X
X
X
X
Torque
status
Status torque result.
1 byte
ASCII
Character
O = OK
L = Low
H = High
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
2 bits
BF
00 = Not used
01 = OK
10 = High
11 = Low
Torque
status
HIGH
Torque result is
above max limit.
1 bit
0 = Not used
1 = High
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Torque
status
LOW
Torque result is
below min limit.
1 bit
0 = Not used
1 = Low
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Torque
status OK
Torque result is
within limits.
1 bit
0 = Not used
1 = OK
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Tracking
disabled
Tracking function currently disabled
X
X
X
X
